Specifications
Robust & Sturdy, Optimal Fuel efficiency, Low maintenance cost
Application
Gensets, Sugarcane Crusher, Construction equipments, Turbine Pump, Poso Mill, Marine, Mining applications
Technical Data
No.ItemTechnical Data1Method of CoolingAir2No. of Cylinder13Rated Power - B. H. P. / kW10.0/7.44Bore (mm)102.05Stroke (mm)116.06Rated R. P. M.15007Swept Volume (CC)9488Compression Ratio18.0:19Bearing TypeBush / TRB on specific request10Method of StartingCold Starting with the help of Starting Handle / Electric Start can be built up on specific request11Engine RotationStandard Rotation Clockwise facing Flywheel / Anticlockwise can be built up on specific request12Governor Type / ClassCentrifugal / B1 Class (A2 if required)13Fuel OilHigh Speed Diesel (Sp. Gr. 0.82 / 0. 84)14Fuel Tank Capacity11.0 Lts.15Fuel Injection Timing by Spill Cut Off Method27° BTDC16Fuel Injection EquipmentMICO make Nozzle Holder 9 430 032 155Bosch Pump 9 410 031 021Injection Release Pressure 190 / 210 kg / cm217Sp. Fuel Consumption gms / bhp - hr18518Sp. Fuel Consumption gms / Kwhr25119Fuel Filter Type / Capacity (Lts.)Paper Type (Replaceable) / 0.520Bumping Clearance (mm)1.14 - 1.2721Valve Tappet Clearance Inlet (mm)0.1822Valve Tappet Clearance Exhaust (mm)0.2023Air ClearanerOil Bath Washable Type24SilencerMuffler Type25Lubrication SystemPlunger Pump26Lub. Oil Sump Capacity (Lts.)3.50027Lub. Oil StrainerPerforated Tin Sheet Washable Type28Lub. Oil GradePerforated Tin Sheet Washable TypeTemp 5° C & Below - SAE 10Temp 5° C to 34° C - SAE 30Temp 34° C & Above - SAE 4029Crank Shaft Height (mm)20330Foundation Bolt Spacing (mm)292 x 14031Engine Net Weight (kg)18532Engine Gross Weight (kg)25533Overall Dimensions (L x W x H)525 x 590 x 83534Overall Packing Dimensions (L x W x H) (mm)762 x 660 x 908
